OUTDOOR RF
P8AX50-B/MF
Part Number: 60107
- 4GHz Bi-Directional Coaxial Surge Protector - High Energy GDT Technology - Low Insertion Loss - Field Replaceable GDT - Waterproof Design - DC Pass - UL497E Listed
Datasheet
Select another reference:
- P8AX09-716/FF
- P8AX09-716/MF
- P8AX09-B/FF
- P8AX09-B/MF
- P8AX09-F/FF
- P8AX09-F/MF
- P8AX09-SMA/FF
- P8AX09-SMA/MF
- P8AX09-T/FF
- P8AX09-T/MF
- P8AX15-B/FF
- P8AX15-B/MF
- P8AX15-N/FF
- P8AX15-N/MF
- P8AX15-SMA/FF
- P8AX15-SMA/MF
- P8AX25-4310/MF
- P8AX25-716/FF
- P8AX25-716/MF
- P8AX25-B/FF
- P8AX25-B/MF
- P8AX25-F/FF
- P8AX25-F/MF
- P8AX25-N/FF
- P8AX25-N/MF
- P8AX25-SMA/FF
- P8AX25-SMA/MF
- P8AX25-T/FF
- P8AX25-T/MF
- P8AX50-716/FF
- P8AX50-716/MF
- P8AX50-B/FF
- P8AX50-B/MF
- P8AX50-N/FF
- P8AX50-N/MF
- P8AX50-T/FF
- P8AX60-N/FF
| Frequency range | f | DC-3.5 GHz |
| Insertion loss | < 0.2 dB | |
| Return loss | > 20 dB | |
| Impedance | 50 ohms | |
| VSWR | <1.2:1 | |
| Max. load current | IL | 10 A |
| Max. discharge current | Imax | 20 kA |
| Protection mode(s) | Common mode | |
| Impulse current | Iimp | 1 kA |
| Nominal discharge current | In | 5 kA |
| Max Power | 780 W | |
| DC Pass | ZERTZAERTZERTZER | True |
| Insulation resistance | IR | ≥10 GOhms |
| Impedance | Ω | 50 |
| RF Power | W | 780 W |
| Return Loss | db | >20 |
| VSWR | :1 | <1.2:1 |
| Max Total Discharge Current | kA | 20 kA |
| Max Discharge Current | kA | 20 kA |
| DC Pass | Yes | |
| RF SPD TYPE | UL497E LISTED | |
| VOLTS | (V) | 48 |
| AC/DC/DC PV/RF | RF | |
| WIRES | 1W+GROUND | |
| LINE CURRENT MAX | (A) | 10 |
| AMBIENT MIN | (C) | -40 |
| AMBIENT MAX | (C) | +85 |
| IN | (kA) | 10 |
| IMAX | (kA) | 20 |
| FREQUENCY RANGE | (GHz) | 0-4.0 |
| INSERTION LOSS | (db) | <0.2 |
| RETURN LOSS | (db) | >22 |
| VSWR | <1.25:1 |
| Technology | Gas discharge tube | |
| Connection to Network | Connector BNC Male/Female | |
| Mounting | Feedthrough | |
| Housing material | Brass/Surface plating : Cu Zn Sn | |
| Operating temperature | Tu | -40/+85°C |
| Protection rating | IP66 | |
| Outdoor application | Yes | |
| Dimensions | See diagram | |
| Contacts | Bronze/Surface Au-Ag | |
| Insulation material | PTFE | |
| Weight | 0.11 kg | |
| TECHNOLOGY | GDT | |
| CONNECTION METHOD | SERIES CONNECTOR, BI-DIRECTIONAL | |
| MOUNTING | BULKHEAD, OPTIONAL BRACKET | |
| MATERIAL | Cu, Zn, Sn plated Brass, PTFE | |
| NEMA RATING (IP RATING) | NEMA 6P (IP67) | |
| DIMENSIONS | See diagram (mm) | |
| WEIGHT | 0.30 lbs |
| Standards compliance | IEC 61643-21 / EN 61643-21 / UL497C / UL497E | |
| RohS compliance | Yes | |
| UL STANDARD | UL497E | |
| UL CATEGORY | QVLA | |
| UL FILE NUMBER | E349646 | |
| STANDARDS | NOM-003-SCFI-2014, NOM-001-SCFI-1993 | |
| ENVIRONMENTAL STANDARDS | ROHS |
| Operating Temperature | °C | -45 °C |
| Operating Temperature | °C | 85 °C |
| Operating Temperature | °F | -50 °F |
| Operating Temperature | °F | 85 °F |
| Operating Relative Humidity | %RH | Can be submerged |
| Operating Altitude | m | 2000 m |
| Operating Altitude | Ft | 6500 Ft |
| Housing/Enclosure material | Cu, Zn, Sn plated Brass | |
| Mounting | Bracket or throught hole | |
| IP Environmental rating | IP65 | |
| NEMA Environmental rating | NEMA 4 | |
| Installation Location | Indoor / outdoor | |
| Spare part | BB HF 500/20 | |
| Accessories | BK | |
| Product Dimension | mm | 64 mm |
| Product Dimension | mm | 26 mm |
| Product Dimension | mm | 12.2 mm |
| Product Dimension | In | 2.52 In |
| Product Dimension | In | 1.02 In |
| Product Dimension | In | 0.48 In |
| Individual Pack | No | |
| Storage Temperature | °C | -40 °C |
| Storage Temperature | °C | 85 °C |
| Storage Temperature | °F | -40 °F |
| Storage Temperature | °F | 85 °F |
| Waranty | 10 Years |
