OUTDOOR RF

P8AX09-SMA/MF

Part Number: 60501

Call for leadtime/delivery

4GHz Bi-Directional Coaxial Surge Protector - High Energy GDT Technology - Low Insertion Loss - Field Replaceable GDT - Waterproof Design - DC Pass - UL497E Listed

Select another reference:

Electrical Properties Mechanical Properties Norms Install Misc Schematics

Max. DC operating voltage	Uc	72 Vdc
Frequency range	f	DC-3.5 GHz
Insertion loss		< 0.2 dB
Return loss		> 20 dB
Impedance		50 ohms
VSWR		<1.2:1
Max. load current @25°C	IL	10 A
Max. discharge current max. withstand @ 8/20 µs by pole	Imax	20 kA
Nominal discharge current C2 Category	In	5 kA
Protection mode(s)		Common mode
Protection level @1kV/µs (C3)	Up	< 650 V
Impulse current 2 x 10/350µs Test - D1 Category	Iimp	1 kA
Max Power		25 W
Typical let through energy (50 ohms) input 4kV 1.2/50μs - 2kA 8/20μs		300 µJ
DC Pass		Yes
Insulation resistance	IR	≥10 GOhms
Impedance	Ω	50
RF Power Maximum	W	25 W
Return Loss Minimum	db	20
VSWR Maximum	:1	<1.2:1
Max Total Discharge Current Imax (8/20µs x 1)	kA	10 kA
Max Discharge Current Imax (8/20µs x 1)	kA	10 kA
DC Pass		Yes
RF SPD TYPE		UL497E LISTED
VOLTS	(V)	48
AC/DC/DC PV/RF		RF
WIRES		1W+GROUND
LINE CURRENT MAX	(A)	10
AMBIENT MIN	(C)	-40
AMBIENT MAX	(C)	+85
IMAX 8/20µs	(kA)	20
FREQUENCY RANGE	(GHz)	0-4.0
INSERTION LOSS (@ FREQ)	(db)	<0.2
RETURN LOSS	(db)	22
VSWR		<1.25:1

Technology		Gas discharge tube
Connection to Network		Connector SMA Male/Female
Mounting		Bulkhead or Bracket
Operating temperature	Tu	-40/+85°C
Protection rating		IP65
Outdoor application		Yes
Failsafe mode		Short-circuit
Contacts		Bronze/Surface Au-Ag
Insulation material		PTFE
TECHNOLOGY		GDT
CONNECTION METHOD		SERIES CONNECTOR, BI-DIRECTIONAL
MOUNTING		BULKHEAD, OPTIONAL BRACKET
MATERIAL		Housing-Cu, Zn, Sn plated Brass
NEMA RATING (IP RATING)		NEMA 6P (IP67)
DIMENSIONS		See diagram
WEIGHT		0.30 lbs

Operating Temperature Min	°C	-45 °C
Operating Temperature Max	°C	85 °C
Operating Temperature Min	°F	-50 °F
Operating Temperature Max	°F	85 °F
Operating Relative Humidity Max	%RH	Can be submerged
Operating Altitude Min	Ft	2000 Ft
Operating Altitude Max	Ft	6500 Ft
Housing/Enclosure material		Cu, Zn, Sn plated Brass
Mounting		Bracket or Bulkhead through-hole
IP Environmental rating IP		IP65
NEMA Environmental rating NEMA		NEMA 4
Installation Location		Indoor / outdoor
Spare part		BB HF 90/20
Accessories		BK series mounting bracket
Product Dimension L	mm	55 mm
Product Dimension H	mm	26 mm
Product Dimension W	mm	5.9 mm
Product Dimension L	In	2.09 In
Product Dimension H	In	1.02 In
Product Dimension W	In	0.23 In
