OUTDOOR RF

P8AX25-B/FF
Part Number 60114
P8AX25-B/FF
Availability:
$95.00 (excl. tax)
Add to cart

Available within 3 weeks

  • 4GHz Bi-Directional Coaxial Surge Protector - High Energy GDT Technology - Low Insertion Loss - Field Replaceable GDT - Waterproof Design - DC Pass - UL497E Listed
Contact Us
Max. DC operating voltage
 Uc 200 Vdc
Frequency range
 f DC-3.5 GHz
Insertion loss
 < 0.2 dB
Return loss
 > 20 dB
Impedance
 50 ohms
VSWR
 <1.2:1
Max. load current
@25°C
 IL 10 A
Protection mode(s)
 Common mode
Impulse current
2 x 10/350µs Test - D1 Category
 Iimp 1 kA
Nominal discharge current
C2 Category
 In 5 kA
Max Power
 190 W
DC Pass
 Yes
Insulation resistance
 IR ≥10 GOhms
Impedance
 Ω 50
RF Power
Maximum
 W 190 W
Return Loss
Minimum
 db >20
VSWR
Maximum
 :1 <1.2:1
Max Total Discharge Current
Imax (8/20µs x 1)
 kA 20 kA
Max Discharge Current
Imax (8/20µs x 1)
 kA 20 kA
DC Pass
 Yes
RF SPD TYPE
 UL497E LISTED
VOLTS
 (V) 48
AC/DC/DC PV/RF
 RF
WIRES
 1W+GROUND
LINE CURRENT MAX
 (A) 10
AMBIENT MIN
 (C) -40
AMBIENT MAX
 (C) +85
IMAX
8/20µs
 (kA) 20
FREQUENCY RANGE
 (GHz) 0-4.0
INSERTION LOSS (@ FREQ)
 (db) <0.2
RETURN LOSS
 (db) >22
VSWR
 <1.25:1
Technology
 Gas discharge tube
Connection to Network
 Connector BNC Female/Female
Outdoor application
 Yes
Failsafe mode
 Short-circuit
Contacts
 Bronze/Surface Au-Ag
Insulation material
 PTFE
TECHNOLOGY
 GDT
CONNECTION METHOD
 SERIES CONNECTOR, BI-DIRECTIONAL
MOUNTING
 BULKHEAD, OPTIONAL BRACKET
MATERIAL
 Cu, Zn, Sn plated Brass, PTFE
NEMA RATING (IP RATING)
 NEMA 6P (IP67)
DIMENSIONS
 See diagram
WEIGHT
 0.30 lbs
RohS compliance
 Yes
UL STANDARD
 UL497E
UL CATEGORY
 QVLA
UL FILE NUMBER
 E349646
STANDARDS
 NOM-003-SCFI-2014, NOM-001-SCFI-1993
ENVIRONMENTAL STANDARDS
 ROHS
Operating Temperature
Min
 °C -45 °C
Operating Temperature
Max
 °C 85 °C
Operating Temperature
Min
 °F -50 °F
Operating Temperature
Max
 °F 85 °F
Operating Relative Humidity
Max
 %RH Can be submerged
Operating Altitude
Min
 Ft 2000 Ft
Operating Altitude
Max
 Ft 6500 Ft
Housing/Enclosure material
 Cu, Zn, Sn plated Brass
Mounting
 Bracket or throught hole
IP Environmental rating
IP
 IP65
NEMA Environmental rating
NEMA
 NEMA 4
Installation Location
 Indoor / outdoor
Spare part
 BB HF 250/20
Accessories
 BK
Product Dimension
L
 mm 56 mm
Product Dimension
H
 mm 26 mm
Product Dimension
W
 mm 12.2 mm
Product Dimension
L
 In 2.2 In
Product Dimension
H
 In 1.02 In
Product Dimension
W
 In 0.48 In
Individual Pack
 No
Storage Temperature
Min
 °C -40 °C
Storage Temperature
Max
 °C 85 °C
Storage Temperature
Min
 °F -40 °F
Storage Temperature
Max
 °F 85 °F
Waranty
 10 Years
