OUTDOOR RF
Part Number: 6000150
P8AX09-N/FF
- 4GHz Bi-Directional Coaxial Surge Protector - High Energy GDT Technology - Low Insertion Loss - Field Replaceable GDT - Waterproof Design - DC Pass - UL497E Listed
Select another reference:
P8AX09-N/FF
-
P8AX09-716/FF
-
P8AX09-B/MF/75
-
P8AX09-F/FF
-
P8AX09-N/FF
-
P8AX09-N/MF
-
P8AX09-SMA/MF
-
P8AX09-T/FF
-
P8AX09-U/FF
-
P8AX15-F/FF
-
P8AX15-N/FF
-
P8AX15-NWSMA/FF
-
P8AX25-4310/MF
-
P8AX25-716/MF
-
P8AX25-B/FF
-
P8AX25-B/MF
-
P8AX25-NWSMA/FF
-
P8AX25-T/MF
-
P8AX50-4310/MF
-
P8AX50-716/FF
-
P8AX50-B/MF
-
P8AX50-N/FF
-
P8AX50-N/MF
-
P8AX50-NWSMA/FF
- P8AX50-U/FF
- P8AX50-U/MF
-
P8AX60-N/FF
Datasheet
|
Max. DC operating voltage
|
Uc | 72 Vdc |
|
Frequency range
|
f | DC-3.5 GHz |
|
Impedance
|
50 ohms |
|
|
Max. discharge current
max. withstand @ 8/20 µs by pole
|
Imax | 20 kA |
|
Nominal discharge current
C2 Category
|
In | 5 kA |
|
Protection level
@1kV/µs (C3)
|
Up | < 650 V |
|
Impulse current
2 x 10/350µs Test - D1 Category
|
Iimp | 1 kA |
|
Max RF Power
|
25 W |
|
|
Typical let through energy
(50 ohms) input 4kV 1.2/50μs - 2kA 8/20μs
|
300 µJ |
|
|
DC Pass
|
Yes |
|
|
Insulation resistance
|
IR | ≥10 GOhms |
|
Technology
|
Gas discharge tube |
|
|
Connection to Network
|
Connector N Female/Female |
|
|
Mounting
|
Bulkhead or Bracket |
|
|
Operating temperature
|
Tu | -40/+85°C |
|
Protection rating
|
IP65 |
|
|
Outdoor application
|
Yes |
|
|
Failsafe mode
|
Short-circuit |
|
|
Contacts
|
Bronze/Surface Au-Ag |
|
|
Insulation material
|
PTFE |
|
Environmental standards
|
EU RoHS |
|
|
UL STANDARD
|
UL497E |
|
|
UL CATEGORY
|
QVLA |
|
|
UL FILE NUMBER
|
E349646 |
|
|
STANDARDS
|
NOM-003-SCFI-2014, NOM-001-SCFI-1993 |
|
Mounting
|
Bracket or Bulkhead through-hole |
|
|
Accessories
|
BK series mounting bracket |
