Surge Protection for Power Generation Systems

OVERVIEW

Today’s increased reliance on highly sensitive electronics makes surge protection an important topic for Power Generation Systems. The Insurance Institute for Business & Home Safety study found that $26 billion dollars was lost due to non-lightning power surges. In addition, there are about 25 million lightning strikes in the US each year that cause between $650M to $1B in losses according to the Insurance Information Institute, State Farm©.

This article highlights common components of Power Generation Systems to help you develop a comprehensive Surge Protection Solution for your equipment. Each component is listed with a recommended Surge Protective Device (SPD) along with the type of connection protected and the voltage.

backup power system from Adobe stock.
Rooftop emergency backup power system

Emergency Backup Power Supply System

Backup power systems are designed to supply electrical power to vital systems in the event of a power outage. Any damage to or malfunction of the power system equipment can lead to critical system failures when these systems are activated in an emergency.

LocationSystemSurge Protector Model #Link
ATS Line Side Genset277/480 V acMDS750E-277Y
Main Entrance Panel277/480 V acMS100-277Y
Genset Line Side480 V acM50-480D-A
ATS Controller Relay Starter12 V dcDS220S-12DC
Genset Relay Starter12-24 V dcDS220S-24DC
Energy Management Controller I/O6 V dcDLA-06D3 DLA-24D3 v.2



Download Brochure
SPDs for Power Generation
