Surge Protection for Lift Stations

OVERVIEW

Today’s increased reliance on very sensitive electronics makes surge protection an important topic for Water and Wastewater Management. The Insurance Institute for Business & Home Safety study found that $26 billion dollars was lost due to non-lightning power surges. In addition, there are about 25 million lightning strikes in the US each year that cause between $650M to $1B in losses according to the Insurance Information Institute, State Farm©.

This article discusses the various aspects of Water and Wastewater Treatment (WWT) systems to help you develop a comprehensive surge mitigation strategy for your equipment. Each section will conclude with a Surge Protective Device (SPD) Protection Point which identifies where and what SPD to use.

Lift Station | Pump Panel

Lift Station

The lift station, also called the pump station, is a critical element of the wastewater infrastructure. Among the variety of configurations of lift stations they usually house pumps, control panels, backup generators in case of emergencies. Lift stations require reliability for constant use for households, businesses, and industries that each contribute wastewater.

SPD Protection Point - Pump Station

Per the NEC 2020, Article 708.2, defines a Critical Operations Power Systems as one that affects business continuity. A UL listed Surge Protective Device must be installed to be compliant with the NEC.

LocationSystemSurge Protector Model #Link
Automatic Transfer Switch Line Side277/480VacMDS300E-277Y
Automatic Transfer Switch Load Side277/480VacMS100-277Y
Automatic Transfer Switch Line Side Genset277/480VacMS200-277Y
Genset Line Side277/480VacM50-277Y-A M50-A
Main Panel277/480VacMS100-277Y
VFD480VacDS74US-480D DS74US-480D
Control Circuit120VacDS240S-120/G
Battery Charge Controller120VacDS240S-120/G
Pump Controller24VdcDS220S-24DC
Automatic Transfer Switch Relay Starter24VdcDS220S-24DC
Pump Controller I/O4-20mADLA-24D3 DLA-24D3 v.2
SCADAEthernetMJ8-C6A MJ8-C6A


Pump Panel

The pump panel will be common to any industrial wastewater treatment plant, sewage plant or waste management operation. The pump panel will house critical elements not only essential to pumping but also monitoring.

SPD Protection Point - Pump Panel

Per the NEC 2020, Article 708.2, defines a Critical Operations Power Systems as one that affects business continuity. A UL listed Surge Protectiva Device must be installed to be compliant with the NEC.

LocationSystemSurge Protector Model #Link
Service Entrance277/480VacMDS600E-277Y
Distribution Panel277/480VacMS200-277Y
VFD480VacDS74US-480D DS74US-480D
Power Supply120VacDS240S-120/G
Safety Circuit24VdcDS220S-24DC
PLC Measurement Signals4-20mADLA-24D3 DLA-24D3 v.2
PLC CommunicationRS485/RS232DLA-12D3 DLA-24D3 v.2
HMIEthernetMJ8-C6A MJ8-C6A
