P8AX25-6G-SMA/FF
- UL497E LISTED - Imax 20kA (10kA UL) - In 10kA (10kA UL) - Bi-directional - Replaceable Gas Tube
P8AX25-6G-SMA/FF
Part Number:
68514
Availability:
$95.00 (excl. tax)
Add to cart
Shipping is only available to the USA.
OK
Available within 3 weeks
Gas Discharge Tube Technology, DC Pass
Frequency Range 0-6.9GHz
Imax 20kA, 10kA (UL), In 10kA
IP67 Outdoor Rated
SMA Type Connector
Bi-Directional
Replaceable Gas Tube
Datasheet
Tender specifications
Contact Us
Select another reference:
P8AX09-6G-N/FF
P8AX09-6G-N/MF
P8AX09-6G-SMA/FF
P8AX09-6G-SMA/MF
P8AX09-6G-T/FF
P8AX09-6G-T/MF
P8AX25-6G-4310/FF
P8AX25-6G-4310/MF
P8AX25-6G-N/FF
P8AX25-6G-N/MF
P8AX25-6G-SMA/FF
P8AX25-6G-SMA/MF
P8AX25-6G-T/FF
P8AX25-6G-T/MF
Electrical Properties
Mechanical Properties
Norms
Schemas
Max. DC operating voltage
Uc
200 Vdc
Frequency range
f
DC-7 GHz
Insertion loss
< 0.3dB
Return loss
> 18 dB
Impedance
50 ohms
VSWR
<1.3:1
Max. load current
@25°C
IL
10 A
Protection mode(s)
Common mode
Impulse current
2 x 10/350µs Test - D1 Category
Iimp
1 kA
Nominal discharge current
C2 Category
In
5 kA
Max Power
190 W
DC Pass
Yes
Insulation resistance
IR
≥10 GOhms
RF SPD TYPE
UL497E LISTED
VOLTS
(V)
48
AC/DC/DC PV/RF
RF
WIRES
1W+GROUND
LINE CURRENT MAX
(A)
10
AMBIENT MIN
(C)
-40
AMBIENT MAX
(C)
+85
IMAX
8/20µs
(kA)
20
FREQUENCY RANGE
(GHz)
0-6.9
INSERTION LOSS (@ FREQ)
(db)
<0.2
RETURN LOSS
(db)
>22
VSWR
<1.25:1
Connection to Network
Connector SMA Female/Female
Outdoor application
Yes
Contacts
Bronze/Surface Au-Ag
Insulation material
PTFE
TECHNOLOGY
GDT
CONNECTION METHOD
SERIES CONNECTOR, BI-DIRECTIONAL
MOUNTING
BULKHEAD, OPTIONAL BRACKET
MATERIAL
Cu, Zn, Sn plated Brass, PTFE
NEMA RATING (IP RATING)
NEMA 6P (IP67)
DIMENSIONS
See diagram
WEIGHT
0.30 lbs
RohS compliance
Yes
UL STANDARD
UL497E
UL CATEGORY
QVLA
UL FILE NUMBER
E349646
STANDARDS
NOM-003-SCFI-2014, NOM-001-SCFI-1993
ENVIRONMENTAL STANDARDS
ROHS
×
Max. DC operating voltage:
200 Vdc
Frequency range:
DC-7 GHz
CITEL
Reference:
P8AX25-6G-SMA/FF
Part Number: :
68514
Or equivalent
