- UL497E LISTED - Imax 20kA (10kA UL) - In 10kA (10kA UL) - Bi-directional - Replaceable Gas Tube
P8AX09-6G-N/FF
Part Number: 68011
- Gas Discharge Tube Technology, DC Pass
- Frequency Range 0-6.9GHz
- Imax 20kA, 10kA (UL), In 10kA
- IP67 Outdoor Rated
- N-Type Connector
- Bi-Directional
- Replaceable Gas Tube
Datasheet
Select another reference:
| Frequency range | f | DC-7 GHz |
| Insertion loss | < 0.2 dB | |
| Return loss | > 19 dB | |
| Impedance | 50 ohms | |
| VSWR | <1.25:1 | |
| Max. load current | IL | 10 A |
| Max. discharge current | Imax | 20 kA |
| Protection mode(s) | Common mode | |
| Protection level | Up | < 1100 V |
| Impulse current | Iimp | 1 kA |
| Nominal discharge current | In | 5 kA |
| Max Power | 70 W | |
| DC Pass | ZERTZAERTZERTZER | True |
| Insulation resistance | IR | ≥10 GOhms |
| RF SPD TYPE | UL497E LISTED | |
| VOLTS | (V) | 48 |
| AC/DC/DC PV/RF | RF | |
| WIRES | 1W+GROUND | |
| LINE CURRENT MAX | (A) | 10 |
| POWER RATING | (W) | 25 |
| AMBIENT MIN | (C) | -40 |
| AMBIENT MAX | (C) | +85 |
| RESIDUAL VOLTAGE | (V) | 700 |
| IN | (kA) | 10 |
| IMAX | (kA) | 20 |
| FREQUENCY RANGE | (GHz) | 0-6.9 |
| INSERTION LOSS | (db) | <0.2 |
| RETURN LOSS | (db) | >22 |
| VSWR | <1.25:1 | |
| IMPEDANCE | Ω | 50 |
| Technology | Gas discharge tube | |
| Connection to Network | connector N Female/Female | |
| Mounting | Feedthrough | |
| Housing material | Brass/Surface plating : Cu Zn Sn | |
| Operating temperature | Tu | -40/+85°C |
| Protection rating | IP66 | |
| Outdoor application | Yes | |
| Dimensions | See diagram | |
| Contacts | Bronze/Surface Au-Ag | |
| Weight | 0.165 kg | |
| TECHNOLOGY | GDT | |
| CONNECTION METHOD | SERIES CONNECTOR, BI-DIRECTIONAL | |
| CONNECTOR TYPE | N | |
| GENDER | FEMALE TO FEMALE | |
| MOUNTING | BULKHEAD, OPTIONAL BRACKET | |
| MATERIAL | Cu, Zn, Sn plated Brass, PTFE | |
| NEMA RATING (IP RATING) | NEMA 6P (IP67) | |
| DIMENSIONS | See diagram (mm) | |
| WEIGHT | 0.30 lbs | |
| SPARE PART | BA HF 90/20 |
| Standards compliance | IEC 61643-21 / EN 61643-21 / UL497C / UL497E | |
| RohS compliance | Yes | |
| UL STANDARD | UL497E | |
| UL CATEGORY | QVLA | |
| UL FILE NUMBER | E349646 | |
| STANDARDS | NOM-003-SCFI-2014, NOM-001-SCFI-1993 | |
| ENVIRONMENTAL STANDARDS | ROHS |
| Operating Temperature | °C | -45 °C |
| Operating Temperature | °C | 85 °C |
| Operating Temperature | °F | -50 °F |
| Operating Temperature | °F | 85 °F |
| Operating Relative Humidity | %RH | Can be submerged |
| Operating Altitude | m | 2000 m |
| Operating Altitude | Ft | 6500 Ft |
| Housing/Enclosure material | Cu, Zn, Sn plated Brass | |
| Mounting | Bracket or throught hole | |
| IP Environmental rating | IP65 | |
| NEMA Environmental rating | NEMA 4 | |
| Installation Location | Indoor / outdoor | |
| Spare part | BA HF 90/20 | |
| Accessories | BK | |
| Product Dimension | mm | 67 mm |
| Product Dimension | mm | 25 mm |
| Product Dimension | mm | 13.8 mm |
| Product Dimension | In | 2.64 In |
| Product Dimension | In | 0.98 In |
| Product Dimension | In | 0.54 In |
| Individual Pack | No | |
| Storage Temperature | °C | -40 °C |
| Storage Temperature | °C | 85 °C |
| Storage Temperature | °F | -40 °F |
| Storage Temperature | °F | 85 °F |
| Waranty | 10 Years |
