UL TYPE 1 SPD - Imax 40kA - In 20kA - Modular

DS44S-400
Part Number: 461422
DS44S-400
Availability:
$316.00 (excl. tax)
Add to cart
  • UL1449 TYPE 1 LISTED SPD
  • MOV Technology
  • 40kA Surge Current Rating
  • Visual fault indicator and remote contacts
  • 10-Year warranty
Contact Us
Protection mode(s)
 Common mode/Differential mode
POWER SPD TYPE
 UL1449 TYPE 1 LISTED
VOLTS
 (V) 480/277
AC/DC/DC PV/RF
 AC
PHASE
 (PH) 3Y
AMPS
 (A) N/A
AMBIENT MIN
 (C) -35
AMBIENT MAX
 (C) +60
MODES
 L-L, L-N, L-G, N-G
VPR
 (V) 2500/1500/1500/1500
MCOV
 (V) 680/420/420/420
IN
15 impulses 8/20µs
 (kA) 20
SCCR
 (kA) 100
IMAX
8/20µs
 (kA) 40
Iimp
10/350µs
 (kA) 4
TECHNOLOGY
 MOV
NETWORK CONFIGURATION
 3PH, 4W+G, Wye
CONNECTION METHOD
 SPD-Screw Terminal (8-12AWG), Terminal blocks 6AWG
MOUNTING
 Din Rail
MATERIAL
 Thermoplastic UL94-V0
NEMA RATING (IP RATING)
 NEMA 2 (IP20)
FAIL-SAFE BEHAVIOR
 Disconnection via fuse-link
REAL-TIME DIAGNOSTICS
 Visual indicator and remote contacts
DIMENSIONS
 See diagram
WEIGHT
 1.20 lbs
SPARE PART
 DMS40-400
Certification
 CSA / UL Listed
UL STANDARD
 UL1449 5th Edition
UL CATEGORY
 VZCA, VZCA7
UL FILE NUMBER
 E326289
STANDARDS
 NOM-003-SCFI-2014, NOM-001-SCFI-1993
ENVIRONMENTAL STANDARDS
 ROHS
