UL TYPE 4CA - Imax 22kA - In 10kA
Part Number: 897016
MLPXU-277L-W-HE-Ex
- MOV Technology
- UL121201-Hazardous Locations
- UL1449 Type 4CA
- for 120-277Vac LED applications
- Imax 20kA, In 10kA
- LED indicator
- IP67
- ANSI/IEEE C136.2 Extreme
- ANSI/IEEE C62.41 Category C
- 10-year Warranty
Certificates
Datasheet
|
POWER SPD TYPE
|
UL1449 TYPE 4CA for Hazardous Locations |
|
|
VOLTS
|
(V) | 277 |
|
AC/DC/DC PV/RF
|
AC |
|
|
PHASE
|
(PH) | 1 |
|
AMPS
|
(A) | 8 |
|
AMBIENT MIN
|
(C) | -35 |
|
AMBIENT MAX
|
(C) | +75 |
|
MODES
|
L-L, L-G, L-N, N-G |
|
|
MLV
|
(V) | 1280/1190/1220 |
|
MCOV
|
(V) | 320/320/320 |
|
IN
15 impulses 8/20µs
|
(kA) | 10 |
|
SCCR
|
(kA) | n/a |
|
IMAX
8/20µs
|
(kA) | 22 |
|
TECHNOLOGY
|
Hybrid Inductor+Thermal-MOV |
|
|
NETWORK CONFIGURATION
|
2 pole, 2W+G, Single/Spilt Phase |
|
|
CONNECTION METHOD
|
150mm/5.97" #16 AWG Lead Wires |
|
|
MOUNTING
|
FLANGE MOUNT |
|
|
MATERIAL
|
Thermoplastic UL94-V0 |
|
|
NEMA RATING (IP RATING)
|
NEMA 6P (IP67) |
|
|
FAIL-SAFE BEHAVIOR
|
Disconnection via fuse-link |
|
|
REAL-TIME DIAGNOSTICS
|
LED Indicator |
|
|
DIMENSIONS
|
See diagram |
|
|
WEIGHT
|
0.30 lbs |
|
Certification
|
cRUus |
|
|
Environmental standards
|
EU RoHS |
|
|
UL STANDARD
|
UL1449 5th Edition & UL121201 |
|
|
UL CATEGORY
|
VZCA2, VZCA8 & VZCH, VZCH7 |
|
|
UL FILE NUMBER
|
E326289, E527348 |
|
|
UL121201 HAZARDOUS LOCATION
|
Class I, Division 2, Groups A, B, C & D: Operating Temp. T5 |
|
|
STANDARDS
|
IEC 61643-11, NOM-003-SCFI-2014, NOM-001-SCFI-1993 |
|
|
ANSI/IEEE C62.41
|
Category C 20kV/10kA |
|
|
ANSI/IEEE C136.2
|
Extreme Category 20kV/10kA |
