AC POWER
DIN RAIL AC
DS44S-280
DIN RAIL AC
DS44S-280
Part Number:
461122
Datasheet
ULCertificate_DS44S-280%.pdf
CITEL_Certif_TUV_DS4x-280.pdf
Installation Sheet
Tender specifications
Contact Us
Select another reference:
DS41S-400
DS41S-690
DS42S-120
DS42S-230/G
DS43S-230
DS43S-400
DS43S-480
DS43S-690
DS44S-400
Electrical Properties
Mechanical Properties
Norms
Schemas
Total Maximum discharge current
Imax Total
160 kA
Protection mode(s)
Common mode/Differential mode
POWER SPD TYPE
UL1449 TYPE 4CA
AC/DC/DC PV/RF
AC
AMPS
(A)
n/a
AMBIENT MIN
(C)
-40
AMBIENT MAX
(C)
+60
IN
(kA)
20
SCCR
(kA)
n/a
IMAX
(kA)
40
Iimp
(kA)
4
Weight
0.34 kg
CONNECTION METHOD
Screw Terminal (8-12AWG)
MOUNTING
DIN RAIL
MATERIAL
Thermoplastic UL94-V0
NEMA RATING (IP RATING)
NEMA 2 (IP20)
FAIL-SAFE BEHAVIOR
Disconnection via fuse-link
REAL-TIME DIAGNOSTICS
Visual indicator and remote contacts
DIMENSIONS
See diagram (mm)
Certification
UL / EAC / TUV
UL STANDARD
UL1449 5th Edition
UL CATEGORY
VZCA2, VZCA8
UL FILE NUMBER
E326289
STANDARDS
NOM-003-SCFI-2014, NOM-001-SCFI-1993
ENVIRONMENTAL STANDARDS
ROHS
×
