DIN RAIL DC

Select another reference:
Network
 DC or PV network 24Vdc
Max. DC operating voltage
 Uc 38 Vdc
Max. load current
@25°C
 IL 50 A
Total Maximum discharge current
max. total withstand @ 8/20 µs
Imax Total 40 kA
Protection mode(s)
 Common mode
Technology
 MOV
Connection to Network
 By screw terminals: 1.5-10mm² (actives wires) and 2.5-25mm² (ground)
Format
 Plug-in modular box
Outdoor application
 No
Failsafe mode
 Disconnection from DC network
Weight
 0.109 kg
Certification
 UL 497B
