DATA LINE SPD - UL497B LISTED - Imax 20kA - In 5kA
B180-T
Part Number 510602
Available within 3 weeks
- Hybrid SAD-GDT Technology
- UL497B LISTED
- 20kA Imax
- 5kA Imp
- 5kA In
Network
|
RTC, ADSL, SDSL, SHDSL | |
Max. DC operating voltage
|
Uc | 170 Vdc |
Max. frequency
|
f max. | > 10 MHz |
Insertion loss
|
< 1 dB | |
Protection mode(s)
|
Common/Differential mode | |
DATA SPD TYPE
|
UL497B LISTED | |
VOLTS
|
(V) | 150 |
WIRES
|
2W+GROUND | |
LINE CURRENT MAX
|
(A) | 0.3 |
AMBIENT MIN
|
(C) | -50 |
AMBIENT MAX
|
(C) | +85 |
RESIDUAL VOLTAGE
|
(V) | 210 |
MCOV
|
(V) | 170 |
IN
10 impulses 8/20µs
|
(kA) | 5 |
IMAX
8/20µs
|
(kA) | 20 |
Iimp
10/350µs
|
(kA) | 5 |
DATA SPEED
|
(Mbps) | up to 10MHz |
Technology
|
GDT+Clamping diode | |
Connection to Network
|
By screw terminal: cross section 0.4-1.5mm² | |
Format
|
Wall mounting box | |
Failsafe mode
|
Short-circuit - transmision cut-off - fault mode 2 | |
TECHNOLOGY
|
SAD-GDT | |
NETWORK CONFIGURATION
|
2W+G | |
CONNECTION METHOD
|
RJ11 Connector | |
MOUNTING
|
Wall mount | |
MATERIAL
|
Thermoplastic UL94-V0 | |
NEMA RATING (IP RATING)
|
NEMA 2 (IP20) | |
DIMENSIONS
|
See diagram | |
WEIGHT
|
0.30 lbs | |
SPARE PART
|
n/a |
Certification
|
UL 497B | |
UL STANDARD
|
UL497B | |
UL CATEGORY
|
QVGQ | |
UL FILE NUMBER
|
E184939 | |
STANDARDS
|
IEC 61643-11, NOM-003-SCFI-2014, NOM-001-SCFI-1993 | |
ENVIRONMENTAL STANDARDS
|
ROHS |
