DIN RAIL DATA
Part Number: 420412
Certificates
Datasheet
|
Network
|
24 Vac/Vdc |
|
|
Network
|
4 pairs Ethernet 100 Base-TX |
|
|
Nominal line voltage
|
Un | 24 Vac/Vdc |
|
Max. DC operating voltage
|
Uc | 8 Vdc |
|
Max. DC operating voltage
|
Uc | 30 Vac/Vdc |
|
Max. frequency
|
f max. | 125 MHz |
|
Insertion loss
|
< 1dB |
|
|
Insertion loss
|
< 1 dB |
|
|
Max. load current @25°C
|
IL | 300 mA |
|
Max. load current @25°C
|
IL | 5 A |
|
Max. discharge current
max. withstand @ 8/20 µs by pole
|
Imax | 5 kA |
|
Max. discharge current
max. withstand @ 8/20 µs by pole
|
Imax | 10 kA |
|
Nominal discharge current
C2 Category
|
In | 2.5 kA |
|
Nominal discharge current
C2 Category
|
In | 2.5 kA |
|
Protection mode(s)
|
Common/Differential mode |
|
|
Protection Level
C3 (10/1000μs), 300 applications@10 A, Y-Y (Line/Line)
|
Up | 220 V |
|
Protection Level
C3 (10/1000μs), 300 applications@10 A, Y-C (Line/Earth)
|
Up | 220 V |
|
Protection level L/N
@ In (8/20µs)
|
Up L/N | 20 V |
|
Protection level L/N
@ In (8/20µs)
|
Up L/N | 20 V |
|
Network type
|
POE Network |
|
|
Technology
|
MOV+GDT |
|
|
Connection to Network
|
By screw terminals: 2.5mm² max. |
|
|
Format
|
DIN rail or flange |
|
|
Mounting
|
DIN rail or plate (flange) |
|
|
Operating temperature
|
Tu | -40/+85°C |
|
Protection rating
|
IP20 |
|
|
Failsafe mode
|
Disconnection and Power cut off |
