Indoor Cat. 6A 10Gb/s rated POE Surge Protective Device & Mounting Hardware Kit

MJ8-POE-A
Part Number 581519
MJ8-POE-A
Availability:
$79.00 (excl. tax)

Available within 3 weeks

  • POE++ Mode A compatible Surge Protector
  • Cat. 5e compatible
  • Shielded RJ45 connectors
  • 16 kA maximum surge discharge capability
  • Max Transmission up to 1Gbps
  • Max Bandwidth up to 100 MHz
  • UL497B


Select another reference:

Network

1Gb/s on Cat5E S/FTP cabling

Protection modes (network)

CM / DM

Protection modes (POE)

CM (Common Mode)

Transmission standard

IEEE 802.3bt

Max. DC operating voltage
Uc

60 Vdc

Max. operating voltage (POE)
Uc

60 Vdc

Max. frequency, in the channel
f max.

100 MHz

Max. data rate

1 Gbps

Max. load current @25°C
IL

2 A

Max. POE power (4PPOE)

90 W

Max. discharge current
max. withstand @ 8/20 µs, X-C (Line/Earth)
Imax

2 kA

Protection Level
C3 (10/1000μs), 300 applications@10 A, X-X (Line/Line)
Up

80 V

Protection level
C3 (10/1000μs), 300 applications@10 A, X-C (Line/Earth)
Up

700 V

Protection Level
C3 (10/1000µs), 300 applications @ 10A, (Pair-Pair, POE)
Up

700 V

Impulse current
D1 (10/350µs), 2 applications, 8X-C (1&2+3&6+4&5+7&8 - Earth)
Iimp Total

500 A

Nominal discharge current
C1 (1.2/50us / 8/20µs), 300 applications X-X (Line/Line)
In

100V / 50A

Nominal discharge current
C2 (1.2/50us / 8/20µs), 10 applications X-C (Line/Earth)
In

4 kV / 2 kA

Line resistance (± 10%)

~ 0 ohms

Capacitance
@1MHz, X-C (Line/Earth)
C

< 5 pF

NOMINAL DC LINE VOLTAGE
Vdc

48

MAX. DC LINE VOLTAGE
Vdc

60

WIRES

8W+Shield+Ground

LINE CURRENT MAX
(A)

1.6

POWER RATING
(W)

100

AMBIENT MIN
(C)

-40

AMBIENT MAX
(C)

+85

PROTECTION LEVEL
(V)

70

IMAX
8/20µs
(kA)

16

MAX. DATA RATE
Gbps

1

MAX. FREQUENCY
Mhz

100

Technology

GDT+TVS diode

Connection to Network

RJ45 shielded connectors Female input/output

Format

Metallic box with connectors input/output

Accessory(s) provided

Screw, washer, cable shoe, earthing plate, DIN rail adapter

Ingress Protection rating

IP20 (NEMA 2)

Failsafe mode

Transmission cut-off - Fault mode 2 (short-circuit)

Pinout

(1-2)(3-6)(4-5)(7-8)

Weight

0.12 kg / 0.26 lbs

TECHNOLOGY

SAD-GDT

NETWORK CONFIGURATION

Single POE Line

CONNECTOR TYPE

Shielded RJ45

PIN OUT

[1-2][3-6][4-5][7-8]

NEMA RATING (IP RATING)

NEMA 2 (IP20)

DIMENSIONS

See diagram

UL File Number

E184939

Certification

UL 497B

UL STANDARD

UL497B

UL CATEGORY

QVGQ

UL FILE NUMBER

E184939

STANDARDS

NOM-003-SCFI-2014, NOM-001-SCFI-1993

ENVIRONMENTAL STANDARDS

ROHS
