INDOOR RF
Part Number: 632601
CNP06 F/MF
- Coaxial surge protector
- Imax : 20 kA
- Up to 1 GHz
- Connectors : BNC, F, TNC, TV(SE) EJ167
Datasheet
UKCA
|
Network
|
coaxial DC-100 MHz |
|
|
Nominal line voltage
|
Un | 5 V |
|
Max. DC operating voltage
|
Uc | 10 Vdc |
|
Max. frequency
|
f max. | DC-100 MHz |
|
Insertion loss
|
≤ 0.5 dB |
|
|
Return loss
|
≥20 dB |
|
|
Impedance
|
50/75 ohms |
|
|
VSWR
|
< 1.3:1 |
|
|
Max. load current @25°C
|
IL | 0.5 A |
|
Max. discharge current
max. withstand @ 8/20 µs by pole
|
Imax | 20 kA |
|
Nominal discharge current
C2 Category
|
In | 5 kA |
|
Protection mode(s)
|
Common mode |
|
|
Protection level L/N
@ In (8/20µs)
|
Up L/N | 20 V |
|
Impulse current
2 x 10/350µs Test - D1 Category
|
Iimp | 2.5 kA |
|
Max Power
|
4 W |
|
|
DC Pass
|
No |
|
|
Impedance
|
Ω | 50/75 |
|
Return Loss
Minimum
|
db |
|
|
VSWR
Maximum
|
:1 | <1.2:1 |
|
Max Discharge Current
Imax (8/20µs x 1)
|
kA Pair-Pair | 20 kA |
|
Max Total Discharge Current
Imax (8/20µs x 1)
|
kA | 20 kA |
|
Max Discharge Current
Imax (8/20µs x 1)
|
kA wire-wire | 20 kA |
|
Max Discharge Current
Imax (8/20µs x 1)
|
kA Pair-Gnd | 20 kA |
|
Max Discharge Current
Imax (8/20µs x 1)
|
kA | 20 kA |
|
DC Pass
|
Yes |
|
Technology
|
GDT+TVS diode |
|
|
Connection to Network
|
Connector F Male/Female |
|
|
Format
|
Insulating box |
|
|
Mounting
|
On plate |
|
|
Operating temperature
|
Tu | -40/+85°C |
|
Protection rating
|
IP20 |
|
|
Outdoor application
|
No |
|
|
Failsafe mode
|
Short-circuit - transmision cut-off - fault mode 2 |
|
Operating Temperature
Min
|
°C | -40 °C |
|
Operating Temperature
Max
|
°C | 85 °C |
|
Operating Temperature
Min
|
°F | -40 °F |
|
Operating Temperature
Max
|
°F | 85 °F |
|
Operating Relative Humidity
Max
|
%RH | 95 |
|
Operating Altitude
Min
|
Ft | 2000 Ft |
|
Operating Altitude
Max
|
Ft | 6500 Ft |
|
Housing/Enclosure material
|
Metal + Plastic |
|
|
Mounting
|
Surface mount |
|
|
IP Environmental rating
IP
|
IP20 |
|
|
Installation Location
|
outdoor |
|
|
Accessories
|
90° Stainless steel bracket |
|
|
Product Dimension
L
|
mm | 61 mm |
|
Product Dimension
H
|
mm | 24 mm |
|
Product Dimension
W
|
mm | 48 mm |
|
Product Dimension
L
|
In | 2.4 In |
|
Product Dimension
H
|
In | 0.94 In |
|
Product Dimension
W
|
In | 1.88 In |
|
Cable type
|
Coax |
|
Individual Pack
|
No |
|
|
Storage Temperature
Min
|
°C | -40 °C |
|
Storage Temperature
Max
|
°C | 85 °C |
|
Storage Temperature
Min
|
°F | -40 °F |
|
Storage Temperature
Max
|
°F | 85 °F |
|
Individual Pack
|
No |
|
|
Storage Temperature
Min
|
°C | -40 °C |
|
Storage Temperature
Max
|
°C | 85 °C |
|
Storage Temperature
Min
|
°F | -40 °F |
|
Storage Temperature
Max
|
°F | 85 °F |
