POLYPHASER IS 50NX-C2-MA Alternate CITEL CXP25-N/MF-DCB Surge Protector SPD

Citel Logo

POLYPHASER IS 50NX-C2-MA
Comparison CITEL CXP25-N/MF-DCB
Surge Protective Device (SPD)

CITLE CXP25-N-MF-DCB Polyphaser IS-50NX-C2-MA
CITEL
CXP25-N/MF-DCB
RF Surge Protector
POLYPHASER
IS 50NX-C2-MA
RF Surge Protector

Intended Application System

SystemRF Coaxial
Conductors1W+Shield+Ground
ConnectorShielded Coaxial
ConfigurationSingle Coaxial

PRODUCT COMPARISON TABLE

This page collects publicly available data from ul.com and assembles a side by side reference table for a convenient product cross reference.

Manufacturer Citel Logo Polyphaser
UL File #E184939E518677
ModelCXP25-N/MF-DCBIS 50NX-C2-MA

Product Image CITLE CXP25-N-MF-DCB Polyphaser IS-50NX-C2-MA

UL.com Ratings


UL CARD


UL CARD

UL APPROVALLISTEDLISTED
UL MARK
SPD TypeUL497EUL497E
Frequency Range125MHz – 1000MHz125MHz – 1000MHz
Insertion Loss≤ 0.18 dB≤ 0.10 dB
Return Loss @ 90Mhz23 dB24 dB
Return Loss @ 400Mhz43 dB46 dB
Return Loss @ 850Mhz33 dB37 dB
VSWR @ 90Mhz1.13:11.13:1
VSWR @ 400Mhz1.01:11.01:1
VSWR @ 850Mhz1.04:11.02:1
Connector TypeN-TypeN-Type
Connector GenderMale-FemaleMale-Female
Impedance50 ohm50 ohm
Protection CircuitGDT+Capacitor2 Series GDT
+Capacitor
DC CircuitDC BlockDC Block
Imax (kA) 8/20us x 12050
Protection Level @ 2.7kV796 V2,140 V
DC Turn-on Voltage250 Vdc
+/-20%		600 Vdc
+/-20%
Maximum Power (Watts)
220-700MHz		190 W125 W
NEMA Rating
IP Rating		IP55IP20
Installation LocationIndoor or
Outdoor		Indoor
Ambient Min (C)
Operating		-40-50
Ambient Max (C)
Operating		8550
GroundingM6 Screw, Bulkhead, BracketFlange
MountingBulkhead, BracketFlange
Environmental
Rating		ROHSROHS
Warranty10-years10 Year
Limited Warranty
UL data is publicly available with a free account at UL.com. The data has been reviewed by our engineering department. From time to time, the applicants UL file (including CITEL's) may become changed or updated at UL.com due to new testing or corrections to a report. At the time of this comparison you will find this information to be accurate to the UL web site. If you find any information requires an update, please bring to our attention and it will be updated immediately.
