MTL ZoneBarrier ZB24596
Comparison CITEL MJ8-POE-C6A
Surge Protective Device (SPD)

MJ8-POE-A/SD MTL ZoneBarrier ZB24596
CITEL MJ8-POE-C6A
Surge Protector
MTL ZoneBarrier
ZB24596 Surge Protector

Intended Application System

SystemDataline
Conductors8W+Shield+Ground
ConnectorShielded RJ45
ConfigurationSingle POE Line

PRODUCT COMPARISON TABLE

This page collects publicly available data from ul.com and assembles a side by side reference table for a convenient product cross reference.

Manufacturer Citel Logo Eaton Logo
UL File #E184939E175267
Model
MJ8-POE-C6A


MTL ZoneBarrier ZB24596

Product Image MJ8-POE-A/SD MTL ZoneBarrier ZB24596

UL.com Ratings


UL CARD


UL CARD

UL APPROVALLISTEDLISTED
UL MARK
SPD TypeUL497BUL497B
Imax (kA) 8/20us x 11610
In (kA) 8/20us x 15--
limp 10/350us x 2500 A-
Ambient Min (C)-40-40
Ambient Max (C)8585
Max. load current (mA)16001000

Additional
Data Sheet Ratings

NEMA Rating
IP Rating
NEMA 2 (IP20)NEMA 2 (IP20)
Technology
SAD-GDT-
Environmental
Rating
ROHSROHS
Warranty10-years10 Year Limited Warranty
