DIN RAIL PV

DS50VGPVS-1000
Part Number 480361
DS50VGPVS-1000
Availability:
$255.00 (excl. tax)
Add to cart

Available within 3 weeks

  • DC SPD for PV Systems
    - VG Technology for Maximum Performance
    - Zero Leakage Current
    - Zero Current Working
    - Imax : 40kA/pole at 8/20µs
    - In : 20kA/pole at 8/20µs
Contact Us
Select another reference:
POWER SPD TYPE
 UL1449 TYPE 1CA
VOLTS
 (V) 1000
AC/DC/DC PV/RF
 DC PV
PHASE
 (PH) -
AMPS
 (A) N/A
AMBIENT MIN
 (C) -35
AMBIENT MAX
 (C) +85
MODES
 DC+-G or DC--G
MCOV
 (V) 1000/1000/1000
IN
15 impulses 8/20µs
 (kA) 20
SCCR
 (kA) 50
Technology
 VG Technology (MOV+GSG)
Connection to Network
 By screw terminals: 4-25mm²
Format
 Plug-in modular box
Failsafe mode
 Disconnection SPD of the PV line
TECHNOLOGY
 MOV+GSG
NETWORK CONFIGURATION
 3 poles, 2W+G
CONNECTION METHOD
 SPD-Screw Terminal (8-12AWG), Terminal blocks 6AWG
MOUNTING
 Din Rail
MATERIAL
 Thermoplastic UL94-V0
NEMA RATING (IP RATING)
 NEMA 2 (IP20)
FAIL-SAFE BEHAVIOR
 Disconnection via fuse-link
REAL-TIME DIAGNOSTICS
 Visual indicator and remote contacts
DIMENSIONS
 See diagram
Certification
 UL
UL STANDARD
 UL1449 5th Edition
UL FILE NUMBER
 E326289
Waranty
 20 Years
