RACKMOUNT DATA
Part Number: 6254
RAK16-E-C6
- 19`` patch panel surge protector for POE-B
- 32 ports
- In/Out front : RJ45
- Maintenance possible per port
- Secondary Protection
- UL497B
Datasheet|
Network
|
100/1000 BaseT, Ethernet |
|
|
Nominal line voltage
|
Un | 5 Vdc |
|
Max. DC operating voltage
|
Uc | 7.5 Vdc |
|
Max. frequency
|
f max. | 250 MHz |
|
Max. data rate
|
10/100/1000 Mbps |
|
|
Insertion loss
|
< 1 dB |
|
|
Max. load current @25°C
|
IL | 750 mA |
|
Nominal Discharge Current, X-C (Line/Earth)
8/20µs Test x 10 - C2 Category
|
In L/PE | 500 A |
|
Protection Level
C3 (10/1000μs), 300 applications@10 A, Y-Y (Line/Line)
|
Up | 20 V |
|
Protection Level
C3 (10/1000μs), 300 applications@10 A, Y-C (Line/Earth)
|
Up | 20 V |
|
Max. capacitance
|
C | < 8 pF |
|
Capacity
Maximum
|
pF | <8 |
|
Telecom Discharge Current
10/1000
|
kA Pair-Pair | 0,1 |
|
Telecom Total Discharge Current
10/1000
|
kA | 0,1 |
|
Telecom Discharge Current
10/1000
|
kA wire-wire | 0,1 |
|
Telecom Discharge Current
10/1000
|
kA Pair-Gnd | 0,1 |
|
Technology
|
Diode écrêtage |
|
|
Connection to Network
|
RJ45 Female intput/output |
|
|
Format
|
Rack 19'' |
|
|
Mounting
|
Baie 19'' |
|
|
Operating temperature
|
Tu | -40/+85°C |
|
Protection rating
|
IP20 |
|
|
Outdoor application
|
No |
|
|
Failsafe mode
|
Short-circuit |
|
|
Pinout
|
(1-2)(3-6)(4-5)(7-8) |
|
Operating Temperature
Min
|
°C | -40 °C |
|
Operating Temperature
Max
|
°C | 85 °C |
|
Operating Temperature
Min
|
°F | -40 °F |
|
Operating Temperature
Max
|
°F | 85 °F |
|
Operating Relative Humidity
Max
|
%RH | 95 |
|
Operating Altitude
Min
|
Ft | 2000 Ft |
|
Operating Altitude
Max
|
Ft | 6500 Ft |
|
Housing/Enclosure material
|
aluminum |
|
|
Mounting
|
Rack mount |
|
|
IP Environmental rating
IP
|
IP20 |
|
|
Installation Location
|
indoor |
|
|
Product Dimension
L
|
mm | 483 mm |
|
Product Dimension
H
|
mm | 89 mm |
|
Product Dimension
L
|
In | 19.02 In |
|
Product Dimension
H
|
In | 3.504 In |
|
Cable type
|
Ethernet |
|
Individual Pack
|
Yes |
|
|
Storage Temperature
Min
|
°C | -40 °C |
|
Storage Temperature
Max
|
°C | 85 °C |
|
Storage Temperature
Min
|
°F | -40 °F |
|
Storage Temperature
Max
|
°F | 85 °F |
|
Individual Pack
|
Yes |
|
|
Storage Temperature
Min
|
°C | -40 °C |
|
Storage Temperature
Max
|
°C | 85 °C |
|
Storage Temperature
Min
|
°F | -40 °F |
|
Storage Temperature
Max
|
°F | 85 °F |
