DIN RAIL DATA

MSP-VM12
Part Number: 420403
MSP-VM12
Availability:
$113.00 (excl. tax)
Add to cart

Available within 3 weeks

Select another reference:
Network

1 pair signal 0-5 V
Network

12 Vac/Vdc
Network

Signal video
Max. DC operating voltage
 Uc

6 Vdc
Max. DC operating voltage
 Uc

15 Vac/Vdc
Max. DC operating voltage
 Uc

8 Vdc
Max. frequency
 f max.

16 Mhz
Max. frequency
 f max.

100 Mhz
Insertion loss

< 1dB
Insertion loss

< 0.1 dB
Insertion loss

< 1dB
Max. load current @25°C
 IL

300 mA
Max. load current @25°C
 IL

5 A
Nominal discharge current
C2 Category
 In

2.5 kA
Protection mode(s)

Common/Differential mode
Protection Level
C3 (10/1000μs), 300 applications@10 A, X-X (Line/Line)
 Up

20 V
Protection Level
C3 (10/1000μs), 300 applications@10 A, X-C (Line/Earth)
 Up

20 V
Protection level L/N
@ In (8/20µs)
 Up L/N

0.22 kV
IMAX
8/20µs
 (kA)

10
Technology

MOV+GDT
Connection to Network

By screw terminals: 2.5-25mm²
Format

DIN rail or flange
Failsafe mode

Disconnection and Power cut off
