Carril DIN Corriente Alterna (CA)

UL1449
TENSION
 (V)

240

AC
FASE
 (PH)

3H
(A)

N/A
(C)

-40
(C)

+85
MODOS

L-L, L-N, L-G, N-G, H-L, H-N, H-G
(V)

1000/700/700/700/3000/700/700)
(V)

300/150/150/150/470/320/320)
(kA)

20
Icc
cortocircuito
 (kA)

200
(kA)

75
(%)

95%
TECNOLOGIA

Multi-MOV+GSG
CONFIGURACION DE RED

3PH, 4W+G, Hi-Leg Delta
FORMA DE CONEXION

SPD-Screw Terminal (8-12AWG), Terminal blocks 6AWG
MONTAJE

Din Rail

Thermoplastic UL94-V0

NEMA 2 (IP20)
DESCONEXION SEGURA

Disconnection via fuse-link

Visual indicator and remote contacts

See diagram

UL1449 5th Edition

VZCA, VZCA7

E326289
NORMAS

IEC61643-11/EN61643-11, NOM-003-SCFI-2014, NOM-001-SCFI-1993

ROHS
