Carril DIN Corriente Alterna (CA)
Part Number: 33171455
Certificates
Ficha de datos
|
|
UL1449 TYPE 1 LISTED |
|
|
TENSION
|
(V) | 480 |
|
|
AC |
|
|
FASE
|
(PH) | 3D |
|
|
(A) | N/A |
|
|
(C) | -35 |
|
|
(C) | +60 |
|
MODOS
|
L-L, L-G |
|
|
|
(V) | 1800/-/1800/- |
|
|
(V) | 550/-/550/- |
|
|
(kA) | 20 |
|
Icc
cortocircuito
|
(kA) | 100 |
|
|
(kA) | 40 |
|
|
(kA) | 4 |
|
Modo de fallo
|
Desconexión de la red Baja Tensión |
|
|
TECNOLOGIA
|
MOV |
|
|
CONFIGURACION DE RED
|
3PH, 3W+G, Delta |
|
|
FORMA DE CONEXION
|
SPD-Screw Terminal (8-12AWG), Terminal blocks 6AWG |
|
|
MONTAJE
|
Din Rail |
|
|
|
Thermoplastic UL94-V0 |
|
|
|
NEMA 2 (IP20) |
|
|
DESCONEXION SEGURA
|
Disconnection via fuse-link |
|
|
|
Visual indicator and remote contacts |
|
|
|
See diagram |
|
|
|
1.20 lbs |
|
|
|
DSM40U-275 |
|
Certificación
|
CSA / UL Listed |
|
|
Normas ambientales
|
EU RoHS |
|
|
|
UL1449 5th Edition |
|
|
|
VZCA, VZCA7 |
|
|
|
E326289 |
|
|
NORMAS
|
NOM-003-SCFI-2014, NOM-001-SCFI-1993 |
