Z3-650-2
Comparison CITEL M50-480D-B
Surge Protective Device (SPD)

CITEL M50-480D-B Surge Protector	Maclean Z3-650-2 Surge Protector
Intended Application System
System Voltage	480Vac
Number of Phases	3-Phase
Conductors	3 Wire + Ground
Configuration	Delta

PRODUCT COMPARISON TABLE

This page collects publicly available data from ul.com and assembles a side by side reference table for a convenient product cross reference.

Manufacturer
UL File #	E326289	None
Model	${ITEM_LINK#2178940}<-No Item, #2178940 M50-480D-B	Z3-650-2
Product Image	${ITEM_LINK#2178940}<-No Item, #2178940
UL.com Ratings	UL CARD	No UL CARD
UL APPROVAL	LISTED	None
UL MARK		None
SPD Type	UL 1449 5th Ed. Listed Type 1	None
Volt (V)	480	650
AC/DC DC PV	AC	AC
Phase	3D	3D
Amps (A)	n/a	n/a
Ambient Min (C)	-35	-
Ambient Max (C)	80	-
Mode
L-L L-N L-G N-G	L-L n/a L-G n/a	- - - -
VPR (Vpk)
L-L L-N L-G N-G	2500 n/a 1500 n/a	- - - -
MCOV
L-L L-N L-G N-G	560 n/a 560 n/a	- - - -
In (kA)	20	-
SCCR (kA)	150	-
Additional Data Sheet Ratings
Surge Current Rating (kA)	50	10
Protection Circuit	TMOV +GSG	TMOV
Leakage Current	No	Yes
TOV Optimized	Yes	No
Diagnostics	LED/phase & Audible Alarm	Mechanical Indicator
Environmental Rating	NEMA 6	-
# of Wires	4	4
Modes of Protection	Common Mode Differential Mode	Common Mode Differential Mode
Warranty	10-years	1-year

|

UL data is publicly available with a free account at UL.com. The data has been reviewed by our engineering department. From time to time, the applicants UL file (including CITEL's) may become changed or updated at UL.com due to new testing or corrections to a report. At the time of this comparison you will find this information to be accurate to the UL web site. If you find any information requires an update, please bring to our attention and it will be updated immediately.
