ABB OVR T2 3N 40-150 P TS IP20U ALTERNATE CITEL DS73US-120T/G

Citel Logo

OVR T2 3N 40-150 P TS U
Comparison CITEL DS73US-120T/G
Surge Protective Device (SPD)

DS73US-120T-G
CITEL
DS73US-120T/G
Surge Protector
ABB
OVR T2 3N 40-150 P TS U
Surge Protector

Intended Application System

System Voltage240/120
Number of Phases1S
Conductors3W+G
ConfigurationSplit Phase

PRODUCT COMPARISON TABLE

This page collects publicly available data from ul.com and assembles a side by side reference table for a convenient product cross reference.

Manufacturer Citel Logo
UL File #E326289E322885
Model DS73US-120T/G
OVR T2 3N 40-150 P TS U

Product Image DS73US-120T-G

UL.com Ratings

UL CARD UL CARD
UL APPROVALLISTEDRECOGNIZED
UL MARK
SPD TypeType 1Type 4CA (5)
Volt (V)240/120208/120
AC/DC
DC PV
ACAC
Phase1S3Y
Amps (A)n/an/a
Ambient Min (C)-400
Ambient Max (C)7560
Mode
L-L
L-N
L-G
N-G
L-L
L-N
L-G
N-G
L-L
L-N
L-G
N-G
VPR (Vpk)
L-L
L-N
L-G
N-G
1200
800
1500
1200
-
-
-
-
MCOV
L-L
L-N
L-G
N-G
420
210
255
255
350
175
430
255
In (kA)2020
SCCR (kA)200n/a

Additional
Data Sheet Ratings

Surge Current
Rating (kA)
7520
Protection CircuitMOV-GSGMOV
Leakage CurrentNoYes
TOV OptimizedNoNo
DiagnosticsIndicatorIndicator
Environmental
Rating
IP20IP20
# of Wires44
Modes of ProtectionCommon Mode
Differential Mode
Common Mode
Differential Mode
Warranty10-years3-years

|

UL data is publicly available with a free account at UL.com. The data has been reviewed by our engineering department. From time to time, the applicants UL file (including CITEL's) may become changed or updated at UL.com due to new testing or corrections to a report. At the time of this comparison you will find this information to be accurate to the UL web site. If you find any information requires an update, please bring to our attention and it will be updated immediately.
|
